OVERVIEW
Warranty: 5YEARS
Application: Toys, Power Tools, Home Appliances, Consumer Electronics, BOATS, Golf Carts, SUBMARINES, Electric Bicycles/Scooters, Electric Folk lifts, electric vehicles, Electric Wheelchairs, Electric Power Systems, Solar Energy Storage Systems, Uninterruptible Power Supplies
Battery Size: 24V200AH
Brand Name: MAX
Model Number: Uu24V-200A
The charging ratio: 99%
The discharge rate: 93%
Model: UU 24-100
Storage capacity: 2560Wh
Standard capacity: 100Ah/25.6V
Standard charging voltage: 28.8V-30V
Continuously use output current: 80A
Maximum charging voltage: 50V
Reshoot delay protection: 1000mS
Self-Discharge (25°) : <3%/month
Charge method (CC/CV): Operation: -20℃-70℃; Recommendation: 10℃-45℃
Product size: 495±2mm 180±2mm 276±2mm
ITEM
VALUE WARRANTY 5YEARS
FREE INSTALLATION SERVICE
Yes BRAND NAME MAX
MODEL NUMBER
UU24-200 APPLICATION Home, Commercial, Industrial
SOLAR PANEL TYPE
Monocrystalline Silicon BATTERY TYPE Lithium-Ion
CONTROLLER TYPE
MPPT MOUNTING TYPE Roof Mounting
LOAD POWER (W)
2560Wh OUTPUT VOLTAGE (V) 14.4V-15V
OUTPUT FREQUENCY
50Hz WORK TIME (H) 24 hours
PRODUCT
Solar energy system MODEL NO. UU12-200
SOLAR PANEL TYPE
Mono-crystalline silicon
BATTERY TYPE Lithium-Ion,3.2V LiFePO4 battery
STORAGE CAPACITY
2560Wh CONTROLLER TYPE MPPT
OUTPUT FREQUENCY
50Hz OUTPUT VOLTAGE 14.4-15V
CONTINUOUSLY USE CURRENT
100A WARRANTY 5 years
